DAS-8062

20W, 4" Wall Mount Speaker with Power Tap

The DAS-8062 is a two-way 4” wall mount speaker features a sleek minimalist design in black or white colour, offering professional grade sound quality with durable, high-quality materials for a clear and robust audio experience, wide coverage, consistent dispersion, versatile mounting, and a contemporary high-design look that fits into a wide range of decors. This makes DAS-8062 an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality compact indoor/outdoor foreground/background music (and/or paging) applications.

Datasheet Enquiry

Features

Features

  • Fashion minimalist design aesthetic atmosphere, white black for choice.
  • The integration of professional wall design, fine appearance, sophisticated high-grade filing.
  • Focus on sound quality, inverse-phase type design, and equipped with high pitch and low pitch double unit, clear sound level, mellow, transparent, clear and bright, strong bass.
  • Rear power adjustable knob, free choice of input mode.
  • Mesh: made of 1060 pure aluminum, subject to hardening and anti-oxidation treatment, not easy to cause deformation, and never get rusty.
  • Box body: made of UL94V-0 grade fireproof thickened ABS material, durable in use, Safe and reliable.
  • Driver unit: treble diaphragm is made of natural silk film; and bass diaphragms made of polypropylene material, 3-3.5 inches magnetic circuit design.
  • Mounting bracket: precision rust-proof treatment.

Tech Specification

Model DAS-8062
Driver Size 4"×1, 1"×1
Rated Power 20W
Sensitivity (1m, 1W) 90±2dB
MAX. SPL. (1m) 103±2dB
Frequency Response 95Hz-20kHz
Power : 70V 20W-15W-8W-4W-2W
Power : 100V 20W-15W-8W-4W
Power : 8Ω 20W
Constant Voltage 70V/100V
Constant Resistance 8Ω
Dimensions (H×W×D) 255×176×170mm
Net Weight 2.6kg
